- DS-2CD4585F-IZ(H)
| Camera | ||
|---|---|---|
| Image Sensor: | | | 1/1.7″ Progressive Scan CMOS |
| Min. Illumination: | | | 0.01 Lux @ (F1.2, AGC ON), 0.014Lux @ (F1.4, AGC ON), 0 Lux with IR |
| Shutter time: | | | 1 s to 1/100,000 s |
| Slow shutter: | | | Support |
| Lens: | | | 2.8~12mm @ F1.4, 93.6°~31.8° |
| Lens Mount: | | | φ14 |
| Auto Iris: | | | DC drive |
| Adjustment Range: | | | Pan: 0°~355°, tilt: 0°~75°,rotation: 0°~355° |
| Day& Night: | | | IR cut filter with auto switch |
| Wide Dynamic Range: | | | Digital WDR |
| Compression Standard | ||
| Video Compression: | | | H.264/MJPEG/H.264+ |
| H.264 code profile: | | | Baseline Profile / Main Profile / High Profile |
| Video bit rate: | | | 32Kbps~16Mbps |
| Audio Compression: | | | G.711/G.722.1/G.726/MP2L2 |
| Audio bit rate: | | | 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
| Triple Streams: | | | Yes |
| Image | ||
| Max. Image Resolution: | | | 4000 × 3000 |
| Frame Rate: | | | 50Hz: 45fps(2048 × 1536), 50fps@(1920 × 1080, 1280 x 720) 60Hz: 45fps(2048 × 1536), 60fps@(1920 × 1080, 1280 x 720) |
| Third Stream: | | | Independent with Main Stream and Sub Stream, up to 50/60Hz: 10fps@1280 ×720 |
| Image Enhancement: | | | BLC/3D DNR/ROI/Defog |
| Image Settings: | | | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software
or web browser |
| Distortion Correction: | | | Support |
| Regional Cropping: | | | Support |
| Picture Overlay: | | | LOGO picture can be overlaid on video with 128×128 24bit bmp format |
| Day/Night Switch: | | | Auto/Schedule/Triggered by Alarm In |
| Network | ||
| Network Storage: | | | NAS (Support NFS,SMB/CIFS), ANR |
| Alarm Trigger: | | | Motion detection, Dynamic Analysis, Tampering alarm, Network disconnect, IP address
conflict, Storage exception |
| Protocols: | | | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE,
NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Security: | | | User Authentication, Watermark, IP address filtering, Anonymous access |
| System Compatibility: | | | ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
| Interface | ||
| Audio: | | | 1-ch 3.5 mm audio in (Mic in/Line in)/out interface |
| Communication Interface: | | | 1 RJ45 10M/100M/1000M Ethernet port, 1 RS-485 interface |
| Alarm: | | | 1 input, 1 output (up to DC24V 1A or AC110V 500mA ) |
| Alarm Input: | | | 1 |
| Alarm Output: | | | 1 |
| Video Output: | | | 1Vp-p Composite Output (75 Ω, BNC) |
| On-board storage: | | | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Reset Button: | | | Yes |
| Audio | ||
| Environment Noise Filtering: | | | Support |
| Audio I/O: | | | Support dual audio track, stereo |
| Audio Sampling Rate: | | | 16kHz / 32kHz / 44.1kHz / 48kHz |
| Smart Feature-set | ||
| Behavior Analysis: | | | Line crossing detection, Intrusion detection, Region entrance, Region exiting,
Unattended baggage, Object removal |
| Line Crossing Detection: | | | Cross a pre-defined virtual line |
| Intrusion Detection: | | | Enter and loiter in a pre-defined virtual region |
| Region Entrance: | | | Enter a pre-defined virtual region from the outside place |
| Region Exiting: | | | Exit from a pre-defined virtual region |
| Unattended Baggage: | | | Objects left over in the pre-defined region such as the baggage, purse, dangerous
materials |
| Object Removal: | | | Objects removed from the pre-defined region, such as the exhibits on display. |
| Exception Detections: | | | Scene change detection, Sudden audio increase/decrease detection, Audio loss detection,
Defocus detection |
| Recognition: | | | Face detection recognition |
| Statistics: | | | Object Counting (Entrance and Exit object number is accounted and showed on screen
in real time) |
| General | ||
| Operating Conditions: | | | -30 °C – 60 °C (-22 °F – 140 °F) Humidity 95% or less (non-condensing) -H: -40 °C – 60 °C (-40 °F – 140 °F) with smart heater on |
| Power Supply: | | | 24 VAC ± 10%, PoE (802.3af) -H: 24 VAC ± 10%, High PoE (802.3at) |
| Power Consumption: | | | Max. 12 W -H (Smart Heater): 17W |
| Impact Protection: | | | IK10 |
| Weather Proof: | | | IP66 |
| IR Range: | | | 40m(2.8~12mm)/50m(8~32mm) |
| Dimensions: | | | Φ 164.9 × 127 mm(Φ 6.49” ×5”) |
| Weight: | | | 2100g (4.62lbs) |
| Chuẩn bảo vệ | |
|---|---|
| Độ phân giải | |
| Hình dáng | |
| Công nghệ kết nối | |
| Nguồn cấp | |
| Nhãn hiệu | |
| Ống kính | |
| Âm thanh | Tích hợp micro |
| Báo động | Đèn & còi |
| Chống ngược sáng | D-WDR |
| Hình ảnh | Thông thường |
| Nền tảng kết nối | Hik-Connect |
| Thẻ nhớ | 128 GB |
| Theo dõi thông minh | Không |
| Tính năng thông minh | |
| Trợ sáng | Hồng ngoại 40m |
Thông số kỹ thuật
| Chuẩn bảo vệ | IP66 trở xuống (trong nhà) |
| Độ phân giải | 12MP |
| Hình dáng | Bán cầu |
| Công nghệ kết nối | Camera IP |
| Nguồn cấp | 12VDC/24VAC, Poe |
| Nhãn hiệu | Hikvision |
| Ống kính | Cố định |
| Âm thanh | Tích hợp micro |
| Báo động | Đèn & còi |
| Chống ngược sáng | D-WDR |
| Hình ảnh | Thông thường |
| Nền tảng kết nối | Hik-Connect |
| Thẻ nhớ | 128 GB |
| Theo dõi thông minh | Không |
| Tính năng thông minh | Đếm lượt người, Khác |
| Trợ sáng | Hồng ngoại 40m |
