Camera Dome 12MP Ultra-HD Full Smart Feature-set

Camera

• Image Sensor2.54cm (1/1.7inch) Progressive Scan CMOS
• Min. Illumination0.01 Lux @ (F1.2, AGC ON), 0.014 Lux @ (F1.4, AGC ON), 0 Lux with IR
• Shutter Speed1s ~ 1/100,000s
• Slow ShutterSupport
• Lens2.8~12mm @ F1.4, 93.6°~31.8°
• Lens MountΦ14
• Angle AdjustmentPan: 0°~355°, tilt: 0°~75°, rotation: 0°~355°
• Auto-irisDC drive
• Day & NightIR cut filter with auto switch
• WDRDWDR

Compression Standard

• Video CompressionH.264+/H.264/MJPEG
• H.264 TypeBaseline Profile / Main Profile / High Profile
• Video Bit Rate32 Kbps – 16 Mbps
• Audio Compressionn G.711/G.722.1/G.726/MP2L2
• Audio Bit Rate64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2)


• Max. Resolution4000 × 3000
• Frame Rate50Hz: 15fps (4000 × 3000), 22fps (4096 × 2160), 25fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720) 60Hz: 15fps (4000 × 3000), 22fps (4096 × 2160), 24fps (3840 × 2160), 30fps (3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
• Third StreamIndependent with Main Stream and Sub Stream, up to 50Hz: 10fps(1280 × 720)
• Image EnhancementBLC/HLC/3D DNR/ROI/Defog
• Image SettingSaturation, Brightness, Contrast adjustable by client software or web browser
• Regional CroppingSupport
• Day/Night SwitchAuto/Schedule/Triggered by Alarm In
• Picture OverlayLOGO picture can be overlaid on video with 128×128 24bit bmp format

Network

• Network StorageNAS (Support NFS,SMB/CIFS), ANR
• Alarm TriggerMotion detection, Tampering alarm, Network disconnect, IP address conflict, Storage exception
• ProtocolsTCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
• SecurityUser Authentication, Watermark, IP address filtering, Anonymous access
• StandardONVIF (PROFILE S,PROFILE G),ISAPI

Interface

• Audio1-ch 3.5 mm audio in( Mic in/Line in)/out interface, 1 build-in Microphone
• Communication Interface1 RJ45 10M/100M/1000M Ethernet port, 1 RS-485 interface and 1 RS-232 interface
• Alarm1 input, 1 output (up to DC24V 1A or AC110V 500mA )
• On-board storageBuilt-in Micro SD/SDHC/SDXC slot, up to 128 GB
• Reset ButtonYes

Audio

• Environment Noise FilteringSupport
• Audio I/OSupport dual audio track, stereo
• Audio Sampling Rate16kHz / 32kHz / 44.1kHz / 48kHz

Smart Feature-set

• Behavior AnalysisLine crossing detection, Intrusion detection, Region entrance, Region exiting, Unattended baggage, Object removal
• Line Crossing DetectionCross a pre-defined virtual line
• Intrusion DetectionEnter and loiter in a pre-defined virtual region
• Region EntranceEnter a pre-defined virtual region from the outside place
• Region ExitingExit from a pre-defined virtual region
• Unattended BaggageObjects left over in the pre-defined region such as the baggage, purse, dangerous materials
• Object RemovalObjects removed from the pre-defined region, such as the exhibits on display
• Exception DetectionsScene change detection, Sudden audio increase/decrease detection, Audio loss detection, Defocus detection
• RecognitionFace detection recognition
• StatisticsObject Counting (Entrance and Exit object number is accounted and showed on screen in real time)
• Heat MapSupport

General

• Impact ProtectionIK10
• Operating Conditions-30°C – 60 °C (-22 °F – 140 °F), Humidity 95% or less (non-condensing)
• Power Supply12 V DC ± 10%, PoE (802.3af)
• IR DistanceUp to 30m
• Power ConsumptionMax. 9 W
• DimensionsΦ140×121.8 mm (Φ5.51inch × 4.80inch)
• Weight1400 g ( 3.09 lbs)
