Dark Fighter series 2MP Anti-corrsion IR Bullet network camera
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288, 320 × 240)
Liên hệ
- Camera
- Image Sensor1/1.8″ Progressive Scan CMOS
- Min. Illumination0.01 Lux @ (F1.2, AGC ON), 0.014 Lux @(F1.4,AGC ON), 0 Lux with IR
- Shutter Speed1 s to 1/100,000 s
- Slow ShutterSupport
- DNR3D DNR
- WDRDigital WDR
- Day & NightIR cut filter
- Lens2.8 – 12 mm, F1.4: horizontal field of view, 90.1° to 31°,Motorized zooming and auto focus
- Auto-IrisDC drive
- Audio
- Audio CompressionG.711/G.722.1/G.726/MP2L2 /PCM
- Audio Sampling Rate16kHz/32kHz/44.1kHz/48kHz
- Audio I/OSupport
- Image
- Image EnhancementBLC/3D DNR/Defog/EIS
- Target CroppingSupport
- Day/Night SwitchAuto/Schedule/Triggered by Alarm In
- Picture OverlayLOGO picture can be overlaid on video with 128 × 128 24bit bmp format
- Image SettingsRotate mode, saturation, brightness, contrast, etc., adjustable by client software or web browser
- Sub-Stream
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288, 320 × 240)
60Hz: 30fps (704 × 480, 640 × 480, 352 × 240, 320 × 240)
- ROI (Region of Interest)Support 4 customized region for each stream, and face dynamic tracking
- Max. Resolution2592 × 1944
- Main Stream
50Hz: 50fps(1920 ×1080), 25fps(2592 × 1944, 2560 × 1920, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 60fps(1920 ×1080), 30fps(2592 × 1944, 2560 × 1920, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720)
- Third Stream
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288, 320 × 240)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240, 320 × 240)
- Network
- ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
- Interface
- Communication Interface1 RJ45 10M/100M/1000M self-adaptive Ethernet port
- Alarm1 input, 1 output
- Video Output1Vp-p composite output (75 Ω/BNC)
- On-board StorageBuilt-in microSD/SDHC/SDXC slot, up to 128 G
- Housing interface2 anti-corrosion inlets protected by a metal hose
- Compression Standard
- H.264+Support
- H.265+Support
- H.264 TypeBaseline profile/main profile/high profile
- Video Compression
Main stream: H.265/H.264
Sub stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
- H.265 TypeMain profile
- Audio CompressionG.711/G.722.1/G.726/MP2L2 /PCM
- Video Bit Rate32 Kbps to 16 Mbps
- Audio Bit Rate64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
- Smart Feature-set
- Face DetectionHuman face appears in the image can be detected and trigger linkage method
- Exception DetectionScene change detection, defocus detection, audio exception detection
- Line Crossing DetectionCross a pre-defined virtual line
- Intrusion DetectionEnter and loiter in a pre-defined virtual region
- Behavior AnalysisLine crossing detection, Intrusion detection, Region entrance, Region exiting, Unattended baggage, Object removal
- Region EntranceEnter a pre-defined virtual region from the outside place
- Region ExitExit from a pre-defined virtual region
- Unattended BaggageObjects left over in the pre-defined region such as the baggage, purse, dangerous materials
- Object RemovalObjects removed from the pre-defined region, such as the exhibits on display.
- General
- Power SupplyAC24V, 1.7A terminal block
- Material316L stainless steel
- WeightCamera: 9.75 kg (21.5 lb.)
- Power ConsumptionMax. 40 W
- Ingress ProtectionIP67
- HeaterSupport
| Chuẩn bảo vệ | |
|---|---|
| Độ phân giải | |
| Hình dáng | |
| Công nghệ kết nối | |
| Nhãn hiệu | |
| Âm thanh | Tích hợp micro |
| Báo động | Đèn & còi |
| Chống ngược sáng | D-WDR |
| Hình ảnh | DarkFighter |
| Nền tảng kết nối | Hik-Connect |
| Nguồn cấp | |
| Ống kính | |
| Theo dõi thông minh | Không |
| Tính năng thông minh | |
| Thẻ nhớ | 128 GB |
Thông số kỹ thuật
| Chuẩn bảo vệ | IP67 trở lên (ngoài trời) |
| Độ phân giải | 2 MP |
| Hình dáng | Thân trụ |
| Công nghệ kết nối | Camera IP |
| Nhãn hiệu | Hikvision |
| Âm thanh | Tích hợp micro |
| Báo động | Đèn & còi |
| Chống ngược sáng | D-WDR |
| Hình ảnh | DarkFighter |
| Nền tảng kết nối | Hik-Connect |
| Nguồn cấp | 12VDC/24VAC |
| Ống kính | Cố định |
| Theo dõi thông minh | Không |
| Tính năng thông minh | Nhận diện khuôn mặt |
| Thẻ nhớ | 128 GB |
