Camera IP
2MP Low Light Smart Box LPR Camera with housing
-IR5: 850 nm IR wavelength, up to 50 m IR range, visible red light when IR is on
Liên hệ
- Camera
- Image Sensor1/1.8” Progressive Scan CMOS
- Min. IlluminationColor: 0.002 Lux @ (F1.2, AGC ON), B/W: 0.0002 Lux @ (F1.2, AGC ON), 0 Lux with IR
- Shutter Speed1 s – 1/100,000 s, supports slow shutter
- DNR3D DNR
- WDR120dB
- Day & NightIR cut filter with auto switch
- Lens3.8 mm to 16 mm, horizontal field of view: 100.6° to 27.3°,11 mm to 40 mm, horizontal field of view: 35.8° to 11.2°,
- Auto-IrisDC drive
- Lens MountC/CS mount
- Focussupports auto back focus (ABF)
- Audio
- Environment Noise FilteringSupport
- Audio Sampling Rate16kHz/32kHz/44.1kHz/48 kHz
- Audio I/OSupport
- Image
- Image EnhancementBLC /3D DNR/Defog/EIS
- Target CroppingSupport
- Day/Night SwitchAuto/Schedule/Triggered by Alarm In
- Picture OverlayLOGO picture can be overlaid on video with 128 × 128 24bit bmp format
- Image SettingsRotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser
- Sub-Stream50Hz: 25fps (704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (704 × 480, 640 × 480, 352 × 240),
- ROI (Region of Interest)Support 4 fixed region for each stream, and dynamic tracking
- Max. Resolution1920 × 1080
- Main Stream50Hz: 50fps (1920 × 1080, 1280 × 960, 1280 × 720),60Hz: 60fps (1920 × 1080, 1280 × 960, 1280 × 720),
- Third Stream50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240),
- Network
- Network StorageSupport microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
- ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
- Alarm TriggerRoad traffic, motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
- StandardONVIF (PROFILE S, PROFILE G), ISAPI
- General FunctionOne-key reset, anti-flicker, three streams, heartbeat, password protection, privacy mask, watermark, IP address filter
- Interface
- Communication Interface1 RJ45 10M/100M Ethernet port, 1 RS-485 interface, 1 RS-232 interface
- Audio1-ch 3.5mm audio input(line in/mic in), 1-ch 3.5mm audio output,1 build-in microphone(can be turned off),
- Alarm1 input, 1 output
- Video Output1Vp-p composite output (75 Ω/BNC)
- On-board StorageBuilt-in microSD/SDHC/SDXC slot, up to 128 G
- Reset ButtonYes
- Compression Standard
- H.264+Support
- H.265+G.711/G.722.1/G.726/MP2L2
- H.264 TypeBaseline Profile/Main Profile/High Profile
- Video CompressionMain stream: H.264/MPEG4,Sub stream: H.264/MPEG4/MJPEG,Third stream: H.264/MPEG4/MJPEG,
- H.265 Type32 Kbps – 16 Mbps
- Video Bit Rate64Kbps (G.711) /16Kbps (G.722.1) /16Kbps (G.726) /32-160Kbps (MP2L2)
- General
- Power Supply24 VAC ± 10%, terminal block
- DimensionsCamera: 445.3 × 110 × 169.2 mm (17.53″ × 4.33″ × 6.66″),Package: 683 × 223 × 215 mm (26.89″ × 8.78″ × 8.46″),
- Weight5500 g (12.1 lb.)
- Operating Conditions-IR5, -IRA, -INRA: -30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing),-HIRA: -40 °C to +60 °C (-40 °F to +140°F), Humidity 95% or less (non-condensing),
- Power Consumption24 VAC, 0.6 A, max. 14 W,Max. 23 W with IR on,Max. 74 W with heater on,
- Ingress ProtectionIP66
- Heater– HIRA : support
- IR Range
-IR5: 850 nm IR wavelength, up to 50 m IR range, visible red light when IR is on
-IRA: 850 nm IR wavelength, up to 120 m IR range, visible red light when IR is on
-INRA: 980 nm IR wavelength, up to 120 m IR range, invisible when IR light is on
-HIRA: 850 nm IR wavelength, up to 120 m IR range, visible red light when IR is on
| Chuẩn bảo vệ | |
|---|---|
| Độ phân giải | |
| Hình dáng | |
| Công nghệ kết nối | |
| Nhãn hiệu | |
| Âm thanh | Tích hợp micro |
| Báo động | Đèn & còi |
| Chống ngược sáng | WDR 120 dB |
| Hình ảnh | DarkFighter |
| Nền tảng kết nối | Hik-Connect |
| Nguồn cấp | |
| Ống kính | |
| Thẻ nhớ | 128 GB |
| Theo dõi thông minh | Không |
| Tính năng thông minh | |
| Trợ sáng | Hồng ngoại > hoặc = 80m, Hồng ngoại 50m |
Thông số kỹ thuật
| Chuẩn bảo vệ | IP67 trở lên (ngoài trời) |
| Độ phân giải | 2 MP |
| Hình dáng | Thân trụ |
| Công nghệ kết nối | Camera IP |
| Nhãn hiệu | Hikvision |
| Âm thanh | Tích hợp micro |
| Báo động | Đèn & còi |
| Chống ngược sáng | WDR 120 dB |
| Hình ảnh | DarkFighter |
| Nền tảng kết nối | Hik-Connect |
| Nguồn cấp | 12VDC/24VAC |
| Ống kính | Cố định |
| Thẻ nhớ | 128 GB |
| Theo dõi thông minh | Không |
| Tính năng thông minh | Thông thường |
| Trợ sáng | Hồng ngoại > hoặc = 80m, Hồng ngoại 50m |
